Product Introduction
The Coil Inserting Machine is a dedicated automation device designed for automatic feeding and embedding of motor coils. Adopting high-precision cam transmission and layered positioning structure, it runs smoothly with accurate feeding and neat embedding effect. It effectively avoids coil damage and wire jumping during processing, and is widely applicable to batch coil inserting work of various stator and motor accessories.
Key Benefits
▶Precise layered feeding, no coil extrusion or wire damage
▶Optimized mechanical transmission, low noise and steady long-time operation
▶Complete safety interlock protection, preventing misoperation and machine collision
Technical Specifications
|
Machine Name |
Coil Inserting Machine |
|
Processing Range |
Motor stator, inner and outer coil embedding |
|
Control System |
PLC + Touch Screen Intelligent Control |
|
Working Voltage |
220V 50Hz |
|
Inserting Mode |
Automatic fixed-position feeding & inserting |
|
Machine Frame |
Heavy-duty integral welding structure |
Applications & Components
▶Motor stator manufacturing
▶Household fan motor production
▶Water pump motor accessories
Why Choose This Machine
This coil inserting equipment is professionally optimized for motor coil embedding craft, with stable mechanical performance and low failure rate. It supports fast mold replacement and flexible production switching, helping manufacturers save labor and greatly improve assembly efficiency.
Part of Your Smart Factory
The machine can work independently as a single unit or connect with upstream and downstream automated stations. It supports running data statistics and production cycle monitoring, perfectly matching digital workshop lean production management mode.
FAQ(Frequently Asked Questions)
Q: Will the inserting process scratch the enameled wire?
A: Adopting rounded guiding structure and soft feeding rhythm, it can protect enameled wire well without scratching or breaking.
Q: Can it insert coils of different inner diameter specifications?
A: It only needs to replace the corresponding simple fixtures and adjust a few parameters to adapt to multiple coil sizes.
Q: Is it hard for ordinary workers to set parameters?
A: The touch screen adopts simplified menu design, with intuitive operation and no professional skills required.
