Product Introduction

Our Panasonic MSMF012L1V2M Servo Motor is a 100W low-inertia AC servo motor from MINAS A6 series. Built for light-load high-precision motion control, it outputs steady torque and pairs well with matching drives for reliable operation on small automation devices. As an authorized INOVANCE distributor, we provide a full range of industrial automation products and customized solutions.

Key Benefits

▶ IP65 rating suits general industrial environments for long service life

▶ Quick dynamic response cuts cycle time and raises production efficiency

▶ Integrated holding brake locks shaft position securely when power cuts off

Technical Specifications

Parameter	Specification
Model	MSMF012L1V2M, MINAS A6 Low Inertia
Rated Power/Voltage	100W, 200V
Speed	Rated 3000r/min, Max 6000r/min
Torque	Rated 0.32N·m, Stall 0.32N·m, Peak 0.95N·m
Encoder	23-bit Absolute/Incremental System
Brake	Built-in 24V DC holding brake
Max Inertia Ratio	30 times
Structure	38mm flange, key & thread shaft, lead wire, 0.68kg
Protection	IP65 (excluding shaft and wire tip)

Applications & Components

▶Garment tailoring and automatic fabric weaving mechanical tools

▶ Flexible sliding platforms and compact automated handling arms

▶Biological experiment tools and portable medical inspection instruments

Why Choose This Machine

The Panasonic MSMF012L1V2M Servo Motor adopts proven design for stable performance. It is easy to install and integrate, with great cost performance, a trusted choice for precision automation.

Part of Your Smart Factory

The Panasonic MSMF012L1V2M Servo Motor acts as a core control part for smart factories. It realizes precise positioning and data linkage with control systems to run production lines efficiently.
