Product Introduction
The Static Terminal Riveting Machine is a precision-engineered solution designed for high-efficiency, high-precision crimping of copper terminals, wire lugs, and conductive connectors. Built with a rigid, vibration-dampening frame and servo-controlled pressure system, it delivers consistent crimp quality for power distribution, automotive wiring, and industrial automation applications. Unlike manual or semi-automatic tools, this static model eliminates alignment errors and operator fatigue, ensuring every crimp meets IPC, UL, and industry standards. With customizable dies and pressure adjustment, it handles terminals from 0.5mm² to 16mm², making it ideal for small-batch production, quality testing, and high-volume manufacturing lines.
Key Benefits
▶Consistent Crimp Quality
▶Low Maintenance, High Durability
▶User-Friendly Operation
Technical Specifications
|
Crimping Force |
2T / 3T / 5T (Customizable) |
|
Wire Gauge Range |
0.5mm² – 16mm² |
|
Terminal Types |
Copper lugs, cable terminals, busbar connectors |
|
Control System |
PLC + Servo Motor |
|
Operating Voltage |
220V/50Hz (Customizable) |
|
Dimensions (L×W×H) |
600×450×750mm |
|
Weight |
120kg |
|
Crimp Accuracy |
±0.02mm |
Applications & Components
▶Wiring harness industry
▶Electrical switchgear
▶New energy wiring
Why Choose This Machine
Professional terminal riveting equipment manufacturer, mature structure design, strict factory quality inspection. The machine runs smoothly with low noise, supports customized tonnage and molds, provides one-stop solution for terminal processing.
Part of Your Smart Factory
Compact overall structure, small floor space, easy to connect with automated production lines. Support parameter storage and batch production, meet Industry 4.0 intelligent production demands.
FAQ(Frequently Asked Questions)
Q: Can this machine process different sizes of terminals?
A: Yes. It can match different custom molds to process various terminal specifications and wire gauges.
Q: Is it easy for new workers to operate?
A: Equipped with touch screen and button control, simple interface, workers can master operation in a short time.
Q: Can the riveting pressure be adjusted freely?
A: Yes. The pressure, stroke and speed can be set freely on the touch screen to meet different riveting requirements.
