Product Introduction

The Right-end Flange-Mounted Ball Screw Linear Guide Assembly is a timing belt-driven linear module developed specifically for high-speed, long-stroke linear conveying scenarios. Equipped with high-tension steel-core timing belt and dual EGH15CA guide rails, it achieves 1000mm/s high-speed operation while maintaining positioning stability and long-term durability. The one-piece aluminum alloy body features high rigidity and light weight, easily adapting to multi-axis gantry structures and delivering efficient and reliable linear motion solutions for industries like packaging conveying, logistics sorting, and 3C electronics.

Key Benefits

▶Backlash-free high-speed drive

▶Stable heavy-load operation

▶Consistent performance across full stroke

Technical Specifications

Module Model	Right-end Flange-Mounted Ball Screw Linear Guide Assembly
Repeat Positioning Accuracy C/P	±0.02mm / ±0.01mm
Lead	5mm / 10mm / 20mm
Max Horizontal Load	70kg / 47kg / 24kg
Max Vertical Load	17kg / 12kg / 6kg
Max Speed	250mm/s / 500mm/s / 1000mm/s
AC Motor Configuration	200W / 400W
Ball Screw Outer Diameter	Φ16mm / Φ20mm
Linear Guide Brand/Model	EGH15CA
Timing Pulley Model	3M-40-17
External Sensor	SX672 NPN
Internal Sensor	None
Effective Stroke (S)	Overall Length (L)	Standard Blocks (N)	Height (H)
100mm	385mm	1	50
150mm	435mm	1	100
200mm	485mm	1	150
250mm	535mm	1	200
300mm	585mm	2	50
350mm	635mm	2	100
400mm	685mm	2	150
450mm	735mm	2	200
500mm	785mm	3	50
550mm	835mm	3	100
600mm	885mm	3	150
650mm	935mm	3	200
700mm	985mm	4	50
750mm	1035mm	4	100
800mm	1085mm	4	150
850mm	1135mm	4	200
900mm	1185mm	5	50
950mm	1235mm	5	100
1000mm	1285mm	5	150

product-880-411

Applications & Components

▶Precision Inspection Equipment: Inspection station positioning platform, vision scanning sliding table, workpiece alignment fine-tuning mechanism.

▶Robotic Auxiliary Application: Cartesian module combination, gantry beam linear axis, multi-station reciprocating handling unit.

▶Light Industry Non-standard Machinery: Station reciprocating transfer, material automatic feeding, traveling mechanism for small automated assembly lines.

Why Choose This Machine

The Right-end Flange-Mounted Ball Screw Linear Guide Assembly features thickened profile and dual guide rail structure for high rigidity and torsion resistance, ensuring stable operation even under heavy loads. The belt drive requires no daily oiling for low maintenance costs. With standard interface compatible with mainstream motors and control systems, and custom stroke options available, it delivers outstanding cost performance as an ideal drive unit for automation lines.

Part of Your Smart Factory

The Right-side Mounted Flange Ball Screw Linear Guide Rail comes with standard industrial interface, seamlessly compatible with Industry 4.0 smart production lines and mainstream PLC & motion control systems. Its modular structure allows easy multi-axis combination for gantry and linkage setup, supporting real-time operation data feedback for unmanned production in digital workshops and accelerating flexible line deployment.
