Product Introduction
The Ultra-precision Ball Screw Positioning Stage is a high-precision, heavy-duty motion solution engineered for industrial automation with limited installation space. Built with an integrated aluminum alloy frame, precision ball screw and EGH25CA linear guide, it delivers ±0.01/±0.02mm repeat positioning accuracy, supporting horizontal loads up to 150kg and a stroke range of 100–1000mm for diverse production needs.
Key Benefits
▶Built-in SX674NPN sensor as standard, with optional external sensor for customized safety configurations
▶Wide motor compatibility, working with 750W, 1KW and 1.5KW AC motors for flexible system integration
▶Adjustable speed range from 250mm/s to 1000mm/s, balancing motion speed and positioning stability
Technical Specifications
|
Model |
Ultra-precision Ball Screw Positioning Stage |
||
|
Stroke (S) |
mm |
||
|
Repeat Positioning Accuracy (C/P) |
±0.02 / ±0.01 mm |
||
|
Load Capacity (Horizontal, KG) |
150 (Lead 5mm) / 120 (Lead 10mm) / 90 (Lead 20mm) |
||
|
Load Capacity (Vertical, KG) |
60 (Lead 5mm) / 45 (Lead 10mm) / 30 (Lead 20mm) |
||
|
Max. Speed (mm/s) |
250 (Lead 5mm) / 500 (Lead 10mm) / 1000 (Lead 20mm) |
||
|
AC Motor Configuration |
750W / 1KW / 1.5KW |
||
|
Ball Screw Outer Diameter |
Ø25 / Ø32 |
||
|
Guide Rail Brand / Model |
EGH25CA |
||
|
Coupling Model |
P40-55-20 - Motor Shaft |
||
|
Sensor (Built-in) |
SX674NPN |
||
|
Sensor (External) |
Optional |
||
|
Effective Stroke (S) |
Overall Length (L) |
Standard Blocks (N) |
Height (H) |
|
100 |
620 |
1 |
200 |
|
150 |
670 |
2 |
50 |
|
200 |
720 |
2 |
100 |
|
250 |
770 |
2 |
150 |
|
300 |
820 |
2 |
200 |
|
350 |
870 |
3 |
50 |
|
400 |
920 |
3 |
100 |
|
450 |
970 |
3 |
150 |
|
500 |
1020 |
3 |
200 |
|
550 |
1070 |
4 |
50 |
|
600 |
1120 |
4 |
100 |
|
650 |
1170 |
4 |
150 |
|
700 |
1220 |
4 |
200 |
|
750 |
1270 |
5 |
50 |
|
800 |
1320 |
5 |
100 |
|
850 |
1370 |
5 |
150 |
|
900 |
1420 |
5 |
200 |
|
950 |
1470 |
6 |
50 |
|
1000 |
1520 |
6 |
100 |
Applications & Components
▶Custom & Specialized Equipment: Suitable for laboratory precision adjustment, small medical automation and new energy equipment positioning.
▶Industrial Automation Equipment: Perfect for automated inspection machines, packaging sorting systems and linear transfer platforms.
▶Precision Electronics Assembly: Ideal for 3C component assembly, circuit board testing and precision dispensing in digital production workshops.
Why Choose This Machine
The Ultra-precision Ball Screw Positioning Stage combines compact design, high precision and heavy load capacity, making it ideal for space-constrained automation projects. With strict factory calibration, it ensures consistent performance and low maintenance requirements. Its wide compatibility with standard motors and accessories reduces integration costs, while competitive pricing delivers excellent value for small and medium-sized production lines.
Part of Your Smart Factory
The Ultra-precision Ball Screw Positioning Stage combines compact design, high precision and heavy load capacity, making it ideal for space-constrained automation projects. With strict factory calibration, it ensures consistent performance and low maintenance requirements. Its wide compatibility with standard motors and accessories reduces integration costs, while competitive pricing delivers excellent value for small and medium-sized production lines.
FAQ(Frequently Asked Questions)
Q: Is it convenient to replace and upgrade on old equipment?
A: Standard mounting hole spacing and overall size are universal, easy to replace and refit on most old automation equipment.
Q: Can the slider be adjusted manually when power off?
A: Yes, the slider can be pushed and adjusted manually after power cut, convenient for manual debugging and position calibration.
Q: How to choose the right stroke for my machine?
A: It is recommended to reserve 10% margin based on actual moving distance; we can also recommend the most suitable stroke for you according to your equipment structure.
