Product Introduction
The Right-Angle Toothed Belt Driven Linear Actuator with Brake is a robust, fully enclosed linear motion unit with a right-side motor configuration, purpose-built for high-load, long-cycle industrial automation applications. Featuring a reinforced aluminum alloy frame, precision-ground ball screw, and EGH15CA linear guide, it delivers ±0.01~±0.02mm repeat positioning accuracy with exceptional rigidity and minimal deflection under heavy loads. The module supports multiple lead and stroke options, and comes pre-configured with an SX572 NPN external sensor for quick integration into automated control systems. It is ideal for material handling, assembly lines, and precision positioning tasks where high stability and load capacity are required.
Key Benefits
▶ Enhanced Rigidity for Heavy Loads
▶ Precision & Consistency
▶ Right-Mounted Motor Convenience
▶ Versatile Lead & Stroke Options
▶ Ready-to-Integrate Accessories
Technical Specifications
|
Model |
Right-Angle Toothed Belt Driven Linear Actuator with Brake |
||
|
Stroke(S) |
mm |
||
|
Repeat Positioning Accuracy |
±0.01 / ±0.02mm |
||
|
Lead |
5 / 10 / 20mm |
||
|
Max. Horizontal Load(kg) |
70 / 47 / 24 |
||
|
Max. Vertical Load(kg) |
17 / 12 / 6 |
||
|
Max. Speed |
250 / 500 / 1000mm/s |
||
|
AC Motor Configuration |
200W / 400W |
||
|
Ball Screw Diameter |
Ø16 / Ø20 |
||
|
Linear Guide Model |
EGH15CA |
||
|
Coupling Model |
P40-42-10-Motor Shaft |
||
|
External Sensor |
SX572 NPN |
||
|
Effective Stroke(mm) |
L(mm) |
N |
H(mm) |
|
100 |
514 |
1 |
100 |
|
150 |
565 |
1 |
150 |
|
200 |
614 |
1 |
200 |
|
250 |
664 |
1 |
50 |
|
300 |
714 |
2 |
100 |
|
350 |
764 |
2 |
150 |
|
400 |
814 |
2 |
200 |
|
450 |
864 |
3 |
50 |
|
500 |
914 |
3 |
100 |
|
550 |
964 |
3 |
150 |
|
600 |
1014 |
3 |
200 |
|
650 |
1064 |
4 |
50 |
|
700 |
1114 |
4 |
100 |
|
750 |
1164 |
4 |
150 |
|
800 |
1214 |
4 |
200 |
|
850 |
1264 |
5 |
50 |
|
900 |
1314 |
5 |
100 |
|
950 |
1364 |
5 |
150 |
|
1000 |
1414 |
5 |
200 |
Applications & Components
▶Heavy-Duty Automated Assembly
▶Precision Industrial Testing
▶Material Handling & Logistics
Why Choose This Machine
The Right-Angle Toothed Belt Driven Linear Actuator with Brake stands out with its enhanced rigidity and heavy-duty performance, making it ideal for demanding industrial environments where standard modules may falter. The standard right-mount configuration ensures compatibility with most automation systems, while the full range of stroke and lead options allows for tailored performance to match your specific application needs. This module offers a cost-effective solution for upgrading production lines without compromising on precision or durability.
Part of Your Smart Factory
In smart factories, reliability and adaptability are key to maximizing uptime. The Right-Configured Toothed Belt-Driven Linear Motion Unit with Holding Brake serves as a core motion unit in automated assembly, testing, and material handling systems. Its consistent performance reduces unplanned downtime, while its modular design allows for easy integration into new or existing production lines.
FAQ(Frequently Asked Questions)
Q：Can the motor power be upgraded to meet higher speed requirements?
A：Yes, the module supports both 200W and 400W AC motors; a 400W motor is recommended for high-speed or high-load applications.
Q：Does the sealed design of this module affect heat dissipation during long operation?
A：The reinforced aluminum alloy housing acts as a natural heat sink, ensuring efficient heat dissipation even during continuous 24-hour operation.
Q：How does the closed shell protect internal parts?
A：The fully enclosed structure blocks industrial dust, oil mist and debris, reducing part wear and extending the service life of screws and guide rails.
